Double-Sided PVC ID Card Printer — 300 DPI Dye-Sublimation

A dual-sided dye-sublimation printer that produces full-color PVC ID, membership, and event badge cards at 300 DPI with automatic feeding.

45,464.00 ฿
Shipping calculated separately
Lead time: 2–4 weeks

This is a desktop dye-sublimation card printer built for venues that issue their own PVC cards on site — staff IDs, membership and loyalty cards, student cards, or event badges. It prints on both sides of a CR-80 card (the standard 53.98 × 85.6 mm credit-card format) at 300 DPI, so photos, logos, barcodes, and text come out sharp enough for access control and point-of-sale scanning. A 100-card magazine feeds cards automatically, which keeps a front desk or badge station moving during check-in or enrollment rushes.

Print speed scales with the job: single-sided monochrome runs about 4.8 seconds per card, single-sided color about 20 seconds, and full double-sided color about 42 seconds. It handles card thickness from 0.3 mm to 2.0 mm, so you can print standard cards as well as thicker composite stock. The ribbon carries an RFID tag for supply tracking, and connectivity covers USB 2.0 with optional Ethernet and RS232 for shared or networked deployments.

  • Double-sided full-color printing on CR-80 PVC and composite cards
  • 300 DPI resolution for scannable barcodes and legible fine text
  • 100-card automatic magazine for unattended batch runs
  • USB 2.0 standard; Ethernet and RS232 available as options

Backed by a 1-year manufacturer warranty, with call-center and online technical support.

Specifications

Material
PVC, Composite PVC
Dimensions (L × W × H)
188 × 508 × 238 mm
Weight
6.0 kg
Power
60 W
Voltage
AC 100-240V, 50-60Hz; output DC 24V, 2.5A
Warranty
1-year manufacturer warranty
Certifications
FCC, UL, CB, CCC, LVD, CE, CQC, UKCA, RoHS
Customization
Private-mold / ODM/OEM available on request
Print technology
Thermal dye sublimation
Resolution
300 DPI
Print sides
Double-sided
Print speed (single-sided mono)
4.8 s/card
Print speed (single-sided color)
20 s/card
Print speed (double-sided mono)
12 s/card
Print speed (double-sided color)
42 s/card
Card feeding
Automatic via card magazine
Magazine capacity
100 cards (0.76 mm)
Applicable card size
CR-80 (53.98 x 85.6 mm)
Applicable card thickness
0.3 - 2.0 mm
Ribbon type
Special ribbon with RFID
Interfaces
USB 2.0 standard; Ethernet & RS232 optional
Operating temperature
5 - 40 °C
Operating humidity
25 - 85% RH, non-condensing

Frequently asked questions

How long does a card actually take to print?

Roughly 42 seconds for a double-sided full-colour card, 12 seconds double-sided monochrome, 20 seconds single-sided colour and 4.8 seconds single-sided mono. Size your enrolment desk around the job you actually run, not the fastest number.

What card stock does it take?

CR-80 cards only — 53.98 x 85.6 mm, the credit-card format — in PVC or composite PVC, at any thickness from 0.3 mm up to 2.0 mm. That covers standard 0.76 mm cards as well as thicker composite badges.

Can it run a batch unattended?

The magazine holds 100 cards at 0.76 mm and feeds them automatically, so a badging station can be loaded once and left to run through a check-in or enrolment rush.

What do I need to specify when ordering for a networked setup?

USB 2.0 ships on every unit; Ethernet and RS232 are options, so name them on the order if the printer is shared between workstations or sits on a network.

What space and power does it need at the desk?

Allow 508 mm wide by 188 mm deep and 238 mm high on the counter. Power is AC 100-240 V, 50-60 Hz through a 24 V DC 2.5 A supply, drawing 60 W, and it wants 5-40 °C at 25-85% RH non-condensing.

What cover comes with the printer?

A 1-year manufacturer warranty, with call-centre and online technical support behind it. Ribbons carry an RFID tag for supply tracking, so budget consumables around the matched ribbon.
