16-Channel Professional Audio Mixing Console — Bluetooth/USB, 48V Phantom Power
A 16-channel analog mixing console with 48V phantom power, 60mm faders and 24-bit DSP for live sound, stages and conference rooms.
39,189.00 ฿
Shipping calculated separately
Lead time: 2–4 weeks
This 16-channel mixing console is the front-of-house brain for a venue's sound system — it takes every microphone, instrument and playback source, balances them, shapes the tone, and sends a clean stereo mix to the house speakers. The 16 mic inputs handle vocalists and instruments, while four stereo input groups cover backing tracks, media players and DJ feeds. Switchable 48V phantom power runs condenser microphones without external supplies, and the 60mm faders give engineers the long, precise throw they expect on a working board.
Onboard 24-bit DSP adds the effects and routing that used to need a separate rack: PFL/Solo monitoring lets the operator audition any channel in headphones before it hits the mains, and the processing keeps distortion at ≤0.02%. Bluetooth and USB connectivity bring in phone playback, interval music or recorded announcements without extra cabling. With a 20 Hz–30 kHz response and crosstalk over 89 dB, the board stays transparent across the full audio band.
16 mic channels + 4 stereo input groups for bands, panels and multi-source events
Switchable 48V phantom power for condenser microphones
24-bit DSP with PFL/Solo per channel and ≤0.02% distortion
Bluetooth and USB input for wireless and stored playback
Sized at 760 × 520 mm and running on standard 220V mains, it suits bar stages, banquet halls, conference rooms and houses of worship that need reliable, repeatable mixing. Backed by a 3-year manufacturer warranty.
Specifications
Dimensions (L × W × H)
520 × 760 × 66 mm
Weight
11.8 kg
Voltage
AC 220V 50Hz
Warranty
3 years
Certifications
CCC, CQC
Mic inputs
16 channels
Stereo inputs
4 groups
Phantom power
48V
Fader length
60 mm
DSP processor
24-bit
Audio output mode
Stereo
Connectivity
Bluetooth, USB
Frequency response
±1dB, 20Hz–30kHz
Maximum input level
Mic +22dBu, Line +20dBu
Maximum output level
Main +28dBu, Others +22dBu
Crosstalk @1kHz
>89 dB
DSP distortion
≤0.02% @0dB 1kHz 32Ω
THD+N @14dBu, 1kHz
<0.005%
Sensitivity
0VU=+4dBu
Recommended use
Indoor surround sound systems
Frequently asked questions
How do 16 mic channels and 4 stereo groups map to a real event?
Sixteen mic inputs cover a band's vocals, drums and instruments or a full panel of speakers, while the four stereo groups take backing tracks, a media player and a DJ feed without stealing mic channels.
Is phantom power switchable, or global across all inputs?
Switchable 48V phantom power means condenser mics run straight off the board, so you can leave it off for the dynamic mics and ribbon-shy sources on the same console.
Can the operator check a channel before it reaches the house speakers?
PFL/Solo on every channel sends that input to headphones only, so gain, level and a suspect mic get sorted before anything hits the mains.
What bench or table space does the console need?
Allow 760 mm wide by 520 mm deep, with a 66 mm body height — a standard front-of-house table takes it, and the 60 mm faders want the operator seated square to the board.
What power supply should I specify when ordering?
Supplied for AC 220V 50Hz mains, so order it for venues on 220V single-phase; the board carries CCC and CQC certification.
How clean does the signal path stay at working levels?
Frequency response holds ±1dB from 20Hz to 30kHz, THD+N sits under 0.005% at +14dBu/1kHz and crosstalk is better than 89dB, with DSP distortion at or below 0.02%. Warranty is 3 years.
