Professional 2U Class D Power Amplifier — 2x1500W, Stereo/Bridge/Parallel

Name: Professional 2U Class D Power Amplifier — 2x1500W, Stereo/Bridge/Parallel
Brand: BarEquip.Pro
SKU: BEP-0164
Price: 964.0 USD
Availability: BackOrder

A 2U Class D power amplifier delivering up to 5200W bridged, with XLR and Speakon connectivity and full multi-stage protection.

$ 964 $ 1 128 14% discount

Shipping calculated separately

Lead time: 2–4 weeks

This 2U rack power amplifier drives the loudspeakers in a fixed install or touring rig — the link between the mixer and the PA. Its Class D output stage delivers 1500W per channel into 8Ω and 2200W per channel into 4Ω in stereo, rising to 5200W when bridged into a 4Ω subwoofer load, so one chassis can anchor a mid-size room, a multi-zone venue, or a stage.

Three operating modes cover most signal-routing needs: STEREO for independent left/right channels, PARALLEL to feed both outputs from one input, and BRIDGE to combine channels for high-power mono. Balanced XLR inputs and a choice of XLR or 4-pole Speakon outputs let it integrate cleanly into existing patch panels. Front-panel indicators report power, signal, compression, and clipping at a glance.

Frequency response 20Hz–20kHz (±0.5dB) with a signal-to-noise ratio above 108dB
Damping factor above 900 at 1kHz/8Ω for tight low-end control
Layered protection: AC/DC, clipping limiter, short-circuit, thermal, overload, and surge suppression
Two temperature-controlled variable-speed fans, front-to-back airflow
Universal AC 110–240V supply, factory-configurable

Backed by a 3-year manufacturer warranty.

Specifications

Material: Metal
Color: Black
Dimensions (L × W × H): 345 × 483 × 88.6 mm
Weight: 20.0 kg
Power: 5200 W
Voltage: AC 110-240V, 50/60Hz
Warranty: 3 years
Certifications: CCC, CQC
Output power (stereo, 8O, <=1% THD): 2 x 1500 W
Output power (stereo, 4O, <=1% THD): 2 x 2200 W
Output power (stereo, 2O, <=1% THD): 2 x 2800 W
Output power (bridged, 8O, <=1% THD): 4200 W
Output power (bridged, 4O, <=1% THD): 5200 W
Output circuit topology: Class D
Operating modes: Stereo, Parallel, Bridge
Rack size: 2U
Inputs: Female 3-pin XLR x 2
Outputs: Male 3-pin XLR x 2, 4-pole Speakon x 2
Input impedance: 20kO balanced
Input sensitivity: +2.2dBu (1.0Vrms)
Maximum input level: +22.0dBu (10.0Vrms)
Frequency response: 20Hz-20kHz (+/-0.5dB)
Signal-to-noise ratio: >=108 dB
THD (half power, 20Hz-20kHz): 0.07 %
Intermodulation distortion: 0.02 %
Damping factor (1kHz, 8O): >=900
Slew rate: >=60 V/us
Front-panel indicators: Power, signal, compression, clipping
Cooling: 2 DC temperature-controlled variable-speed fans, front-to-back airflow
